This Controller works great for 20 to 35 gallon stills and still boilers as well as our beer keg stills up to 15.5 gallons (must have 2 element ports). You will need to attach your own 60 amp 220 VAC dryer or welding plug to the main power cord so that you can plug the controller in. If you are going to use this heating element controller with your own boiler your boiler will need two , two and two . This controller draws 50 amps @ 11,000 watts 220 VAC Single Phase.

This controller includes:

• (2) Ultra Low Watt Density Heating Element
• (1) Variable Temperature Control
• (2) 30 Amp Twist Lock Male Plugs
• (2) 30 Amp Twist Lock Female Plugs
• (2) Industrial Power Switches
• (1) 40 Amp SSR
• (2) 30 Amp 2 Pole Breakers
• (1) 30 Amp Panel Meter
• (2) 12' cords from the Controller to the Element Boxes
• (1) Lidded enclosure
• (2) Green Power On Lights

Disclaimer: Any person or entity that uses information or equipment provided by Affordable Distillery Equipment, LLC does so entirely at their own risk and accepts all liability concerning the use of the aforementioned equipment and information.
